Goulds 3196 ANSI Standard Dimension Process Centrifugal Pump was first introduced in 1961, it immediately became the standard in the industry. Today, the number of installations attest to its remarkable performance. Users in chemical, petrochemical, pulp & paper, primary metals, food & beverage and general industries know they can make no better choice than the best - Goulds Model 3196.
GOULDS PUMP Model 3196 || Process Pump installed beyond 1 million worldwide
Specifications
- Capacities to 7000 GPM (1590 m 3 /h)
- Heads to 730 feet (223 m)
- Temperatures to 700° F (371° C)
- Pressures to 375 PSIG (26 bar)
Design Features
- Fully Open Impeller
- Engineered Seal Chambers
- Patented Taperbore™ PLUS Seal Chamber
- BigBore™ Seal Chambers
- i-FRAME Power Ends
- Onboard Condition Monitoring
- Inpro VBXX-D Hybrid Bearing Isolators
- Optimized Sump Design
- Premium Severe Duty Thrust Bearings
- LTi Power End for High Load Applications
- Engineered Pump Mounting Systems
- Ease of Maintenance
- Back Pull-out Design
- External Impeller Adjustment
- Maximum Interchangeability
- Optional C-Face Motor Adapter
- Optimum Hydraulic Performance
- Fully Open Impeller
- Full 50/60 Hz Coverage
- 29 Sizes
- Pump Selection Software
- Safety
- Heavy Duty Casings
- Hydrostatic Testing of All Pressure Retaining Components
- ANSI B15.1 Coupling Guard
- Ductile Iron Frame Adapter
- Optional Shaft Guard
Proven Performance
Over One Milltion Process Pump Installations Worldwide
Design Features for Extended Pump Performance
Before Selecting a Process Pump...Consider our Four Design Features for Extended Pump Performance
Total Cost of Ownership
Low Total Cost of Ownership
Goulds Dynamic Seal
Eliminate Sealing Problems and Reduce Maintenance Costs
Goulds Patent Pending i-FRAME Power Ends
Extended Pump Life Through Intelligent Design
Baseplate Mounting Systems
Goulds offers a complete range of pump mounting systems to meet plant requirements; making installation and maintenance easier.
Seal Flush Plans
All ANSI B73.1 seal flush and cooling plans are available to control emission levels, and meet seal installation requirements. Goulds can also provide other special arrangments of user preference.
High and Low Temperature Capability
Options are readily available for high and low temperature applications or where pumpage temperature must be controlled.
Bonus Interchangeability
i-FRAME Power Ends Fit 7 Different Process Pumps
Other Features for Safety Reliability
Adapters, Casings, and Guards Available
